This product may require up to a 6 week lead time due to limited availability.
You can use our prepregs any number of ways including, but not limited to, autoclave, press, vacuum, and compaction tapes. Since most shops do not have access to an autoclave or heated press, the latter two options are mostly used for smaller operations. Due to this prepreg’s specific uni-directional fiber orientation, you would use this prepreg in designs that need increased strength and stiffness in one direction. The fiber gives you medium stiffness, medium strength and maximum versatility.
Prepregs have special policies related to returns and shipping. Please review them here prior to order.
| P/N | 14003-LYD |
|---|---|
| Brand | Mitsubishi / Newport |
| Cure Ply Thickness (CPT) | 0.0046" |
| Exportable | No |
| Fiber Areal Weight | 120 GSM |
| Fiber Type (brand) | TR50S (Grafil) |
| Materials | Standard Modulus Carbon |
| Prepreg Overall Weight | 190 GSM |
| Recommended Cure Temperature | 250F (121C) |
| Resin Content | 35% |
| Resin System | Newport 301 |
| Shelf Life @ 0°F / 40°F / 70°F | 6 Mo / 90 Days / 21 Days |
| Tensile Modulus, msi | 35.0 |
| Tensile Strength (ksi) | 710.0 |
| Weight | 0.38 |
| Width | 39.37 |
