Prepreg - Carbon Fiber (Hexcel AS4) Epoxy (Newport 321) - 0.01" Thick - Standard Modulus - 3k Plain Weave (356 gsm OAW) - 250F Resin - 625 Sqft (+/- 25 Sqft) Roll

productname image number 0
productname image number 1
productname image number 0
productname image number 1
P/N: 14014-D-FULLROLL

Full Roll ◾ ~50 LYD per Roll◾ ~150 Lft. Per Roll ◾ 600 to 650 Sqft.

P/N: 14014-D-FULLROLL
1
$6,496.99
2 - 3
$6,247.79
4 +
$5,976.59
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.
Efficient, Clean & Easy to Use - Full Rolls Available
Prepreg - Carbon Fiber (AS-4) - 0.01" Thick - Standard Modulus 3k Plain Weave (356 gsm OAW) - 250F Resin - ~625 Sqft. Roll - ~50 LYD per Roll

Additional Information

P/N 14014-D-FULLROLL
Brand Mitsubishi / Newport
Cure Ply Thickness (CPT) 0.010"
Exportable No
Fiber Areal Weight 196 GSM
Fiber Type (brand) AS4 (Hexcel)
Materials Standard Modulus Carbon
Prepreg Overall Weight 356 GSM
Recommended Cure Temperature 250F (121C)
Resin Content 45%
Resin System Newport 321
Shelf Life @ 0°F / 40°F / 70°F 6 Mo / 90 Days / 21 Days
Tensile Modulus, msi 33.5
Tensile Strength (ksi) 643.0
Weight 46.0
Width 50.0
Contact Info
Prepreg - Carbon Fiber (Hexcel AS4) Epoxy (Newport 321) - 0.01" Thick - Standard Modulus - 3k Plain Weave (356 gsm OAW) - 250F Resin - 625 Sqft (+/- 25 Sqft) Roll
P/N 14014-D-FULLROLL
