Prepreg - Carbon Fiber - 0.006" Thick - High Modulus - Unidirectional (230 gsm OAW) - 250F Resin - ~61 LB. Roll - 132 LYD Roll

No Image found image number 0
No Image found image number 0
P/N: 14076-D-FULLROLL
Available Now: 1

Full Roll ◾ 61 Lb. Per Roll

P/N: 14076-D-FULLROLL
Available Now: 1
$4,739.99
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.
If there is an Available Now quantity listed above, it indicates our quantity in stock. Orders placed today for this quantity or less are expected to ship the next business day.
Efficient, Clean & Easy to Use - Full Rolls Available
Prepreg - Carbon Fiber - 0.006" Thick - High Modulus - Unidirectional (230 gsm OAW) - 250F Resin - ~61 LB. Roll - 132 LYD Roll

You may also need

Additional Information

P/N 14076-D-FULLROLL
Brand Rock West Composites
Cure Ply Thickness (CPT) 0.006"
Exportable Yes
Fiber Areal Weight 150 GSM
Fiber Type (brand) M40J (Toray)
Materials High Modulus Carbon
Prepreg Overall Weight 230 GSM
Recommended Cure Temperature 250F (121C)
Resin Content 35%
Resin System Propreg 250F
Shelf Life @ 0°F / 40°F / 70°F 6 Mo / 90 Days / 21 Days
Tensile Modulus, msi 55.0
Tensile Strength (ksi) 640.0
Weight 61.0
Width 39.37
