Carbon Fiber Plate - QISO Tri-Axial - Standard Modulus - Gloss / Matte - 12" x 12" x 3/64"
Carbon Fiber Plate - QISO Tri-Axial - Standard Modulus - Gloss / Matte - 12" x 12" x 3/64"
$63.99
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.
If there is an Available Now quantity listed above, it indicates our quantity in stock. Orders placed today for this quantity or less are expected to ship the next business day.
Click to view and choose plate sizes available
Each layer of QISO® quasi-isotropic fabric is a balanced braid with fibers running 0°, + 60° and -60°. In this configuration, our QISO plate will exhibit similar properties in all directions of the laminate. A thicker laminate is not needed with QISO, so we offer it in a two-ply layup. Stronger, lighter and more efficient, QISO® enables superior performance when loads come from multiple directions.
Additional Information
| Application | Multi-Rotor / Drone / UAV |
|---|---|
| Materials | Standard Modulus Carbon |
| Pattern | Tri-Axial Weave |
| Color | Black |
| Finish | Gloss / Matte |
| Panel Thickness | 0.050000 |
| Plate / Panel Size | 12" x 12" / 304.8mm x 304.8 mm |
| Width | 12.0 |
| Thickness | 0.05 |
| Length | 12 |
| Length (max continuous) | 12.0 |
| Areal Density | 0.396 |
| Volumetric Density | 0.055 |
| Weight | 0.396 |
| Primary Fiber | Hexcel AS4 |
| Primary Resin / Hardener | Rhino 1411/4111 |
Engineering Properties
All laminate properties and mechanical calculations are based on Classical Lamination Theory and should be used as a reference only. Rock West Composites does not guarantee these properties or calculations.
| Avg EX Young's Modulus | 6664000.0 |
|---|---|
| Avg EY Young's Modulus | 6664000.0 |
| GXY Shear Modulus | 2546000.0 |
| X Tensile Yield Strength | 62320.0 |
| X Compressive Yield Strength | 55760.0 |
| Y Tensile Yield Strength | 62320.0 |
| Y Compressive Yield Strength | 55760.0 |
| XY Shear Strength | 30444.0 |
| CTEX | 2.00E-06 |
| CTEY | 2.00E-06 |
| Poisson's Ratio vXY | 0.309 |
| Poisson's Ratio vYX | 0.309 |
Note:
- "X" is along the length of a tube, rod, plate, or panel.
- "Y" is around the perimeter of a tube, perpendicular to the length of pultruded parts, or along the width of a plate or panel.
Layup Orientation
202-11 Rev C
| Ply # | Orientation (degrees) | Location |
|---|---|---|
| 1 | All 0/60/-60 (Triaxial) | Inside |
- 0° fibers maximize bending stiffness and run along the length of the part. Consider bending a tube over your knee.
- 45° fibers maximize torsional stiffness and are typically plied together in an opposing manner, i.e. ±45°. Consider twisting a tube like a vehicle's driveshaft.
- 90° (or "hoop") fibers maximize crushing stiffness and generally assist in overall durability. Consider laying a tube on the ground and stepping on it.
