Tube - Rectangle - Fabric - 2.00 x 4.00 - 2.175 x 4.220 Inch

No Image found image number 0
No Image found image number 0
105" Length
P/N: 25521
Available Now: 1
1 - 3
$1,069.99
4 - 9
$1,010.79
10 - 24
$980.59
25 +
$929.39
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.

Unlike metals which have similar properties in all directions (isotropic), the properties of composites are varying, dependent on the orientation of the fibers in each layer. This particular carbon fiber fabric rectangle tube has an internal diameter (ID) of 2.0" x 4.0" (flat to flat) and an outer diameter (OD) of 2.175" x 4.22" (flat to flat). The outer ply of material on this tube is a 2x2 twill weave (diagonal appearance seen below) which will prevent fiber breakout better than unidirectional material. Thus, fabric tubes provide an ideal surface for machining. The core of this tube is almost always comprised of multi-directional "uni" plies which makes most carbon fiber fabric & unidirectional tubes ideal for bending and compression applications.

Rectangle 2.0" x 4.0" Roll Wrapped Fabric Tubing Facts

  • Ideal for bending and compression applications
  • 2x2 twill weave provides a traditional carbon fiber aesthetic
  • Gloss Cello Wrap Finish
  • Learn about our Roll Wrapping Process

You may also need

Product Specifications

Internal Corner Radius: 3/16"

External Corner Radius: 1/4"

Additional Information

P/N 25521
Application Tooling Plates / Support Structures
Shape Rectangular
Materials Standard Modulus Carbon
Pattern 3k 2X2 Twill Weave
Color Black
Finish Cello Wrap Gloss
Height 2.175
Major ID 4.0
Major OD 4.0
Minor ID 2.0
Minor OD 2.0
Inner Corner Radius 0.25
Outer Corner Radius 0.3125
Length 105
Length (max continuous) 105.0
Linear Density 0.778
Volumetric Density 0.055
Weight 6.806
Primary Fiber Tenax UTS50
Primary Resin / Hardener Eporite EHM32
