Plate - Carbon Kevlar - Blue - Twill - Gloss/Matte - 6 x 6 x 0.115" / 2.9mm thick - BLOWOUT

P/N: 603B-66
Available Now: 2

6" x 6" ◾ 152mm x 152mm - BLOWOUT

P/N: 603B-66
Available Now: 2
$34.99
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.
If there is an Available Now quantity listed above, it indicates our quantity in stock. Orders placed today for this quantity or less are expected to ship the next business day.

Click to view and choose plate sizes available

When it comes to strength, there is not much out there stronger than aramid (a.k.a. Kevlar). Our 6" x 6" x 0.115" thick plate is made through a process called resin infusion in combination with vacuum bagging to achieve near perfection, porous free laminates! Our 0.115" carbon fiber/blue Kevlar hybrid laminates consist of two layers of 13010-BLUE-D and three layer of 13000-D in between. Carbon/blue Kevlar plates are ideal for strength and striking good looks!

Quick Facts for our 6" x 6" x 0.115" Thick Carbon/blue Kevlar Gloss/Matte Plate
  • Top side carbon/Kevlar® - gloss surface
  • Bottom side carbon/Kevlar® - matte textured surface
  • Three Layers of carbon core - 670 GSM 12k twill fabric (13000-D)
  • 0.15 lbs / in^3 OR 68.03 grams / cm^3
  • Ready for machining or waterjet cutting
  • Minimal to zero fatigue failures
  • Structurally sound and cosmetically stunning
  • Ideal for RC models including multi-rotor airframes
  • Service temperatures easily exceed 200°F

Additional Information

P/N 603B-66
Clearance Yes
Finish Gloss / Matte
HTS - Harmonized Tariff Code 6815.13.0000
Materials Standard Modulus Carbon + Kevlar
Plate / Panel Size 6" x 6" / 152.4mm x 152.4mm
Thickness 0.115
Weight 0.22
Width 6.0

Tolerances

STOCK TOLERANCE SHEET

Download PDF

Layup Orientation

Carbon/kevlar triple layer plate layup
