Aramid - Honeycomb Core - 3.0 lbs/Cubic ft - 0.960” Thick

P/N: NOM-0960-24-D
Available On Backorder

Aramid Honeycomb ◾ 24" x 48" x 0.96"

$324.99
Estimated lead time for quantities greater than what is Available Now is expected to be at least 4 weeks.
Aerospace grade aramid fiber honeycomb exhibits outstanding flammability properties. It is manufactured from Meta-Aramid paper and coated with a heat resistant phenolic resin.

Features & Benefits (P/N NOM-0960-24-D)

This aerospace honeycomb uses include aircraft galleys, flooring, partitions, aircraft leading and trailing edges, missile wings, radomes, antennas, military shelters, fuel tanks, helicopter rotor blades and navy bulkhead joiner panels.

  • Fire resistant (self extinguishing)
  • High strength-to-weight ratio
  • Corrosion resistant
  • Excellent dielectric properties
  • Thermally insulating
  • High toughness
  • Excellent creep and fatigue performance
  • Good thermal stability
  • Compatible with most adhesives used in sandwich composites
  • Long shelf life. The mechanical properties referenced are maintained for 10 years minimum if not exposed to moisture, weather or any normal hazard.

Additional Information (P/N NOM-0960-24-D)

Materials Aramid
Pattern Honeycomb
Cell Size 0.125
Width 24.0
Thickness 0.96
Length 48
Length (max continuous) 48.0
Areal Density 0.24
Volumetric Density 0.00174
Weight 1.92

Technical Data (P/N NOM-0960-24-D)

Aramid Honeycomb Core Data

Download PDF

Tolerances (P/N NOM-0960-24-D)

  • Length: ± 0.5"
  • Width: ± 0.5"
  • Thickness: ± 0.006″ (under 2″ thick)
  • Density: ±10%
  • Cell Size: ±10%
