Prepreg - Carbon Fiber (Grafil HR40) Epoxy (Newport 321) - 0.0034" Thick - High Modulus - Unidirectional (134 gsm OAW) - Approximately 70 lbs on a Roll - MUST SHIP FREIGHT

productname image number 0
productname image number 1
productname image number 2
productname image number 3
productname image number 4
productname image number 5
productname image number 0
productname image number 1
productname image number 2
productname image number 3
productname image number 4
productname image number 5
P/N: 14008-D-FULLROLL

Full Roll ◾ Approximately 70 Lb. Per Roll

P/N: 14008-D-FULLROLL
$8,899.99
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.
Efficient, Clean & Easy to Use - Full Rolls Available
Prepreg - Carbon Fiber (HR40) - 0.0034" Thick - High Modulus Unidirectional (134 gsm OAW) - 250F Resin - 70 LB. Roll

Additional Information

Materials High Modulus Carbon
Pattern Unidirectional
Color Black
Width 39.37
Cure Ply Thickness (CPT) 0.0034"
Length 0
Fiber Areal Weight 80 GSM
Prepreg Overall Weight 134 GSM
Weight 70.0
Fiber Type (brand) HR40 (Grafil)
Recommended Cure Temperature 250F (121C)
Shelf Life @ 0°F / 40°F / 70°F 6 Mo / 90 Days / 21 Days
Resin Content 40%
Resin System Newport 321

Tolerances

Roll weight may fluctuate +/- 3%.
