Prepreg - Carbon Fiber (Grafil MR60H) Epoxy (Newport 301) - 39.7" x 0.0046" Thick - Unidirectional Intermediate Modulus (174 gsm OAW) - 250F Resin - 42 lb Roll *EXPIRED MATERIAL. BATCH # UNI12022101167 ROLL # 16 OR 20

productname image number 0
productname image number 1
productname image number 0
productname image number 1
P/N: 14019-D-FULLROLL
Available Now: 1

Full Roll ◾ 42 Lb. Per Roll.

P/N: 14019-D-FULLROLL
Available Now: 1
$4,849.99
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.
If there is an Available Now quantity listed above, it indicates our quantity in stock. Orders placed today for this quantity or less are expected to ship the next business day.
Efficient, Clean & Easy to Use - Full Rolls Available
Prepreg - Carbon Fiber (MR60H) - 0.0046" Thick - Unidirectional Intermediate Modulus (174 gsm OAW) - 250F Resin - 42 lb Roll

Additional Information

Materials Intermediate Modulus Carbon
Pattern Unidirectional
Color Black
Width 39.37
Cure Ply Thickness (CPT) 0.0046"
Length 0
Fiber Areal Weight 109 GSM
Prepreg Overall Weight 174 GSM
Weight 42.0
Fiber Type (brand) MR60H (Grafil)
Recommended Cure Temperature 250F (121C)
Shelf Life @ 0°F / 40°F / 70°F 6 Mo / 90 Days / 21 Days
Resin Content 37%
Resin System Newport 301

Technical Specifications

MR60H FIBER DATA SHEET

Download PDF

RESIN SYSTEM DATA SHEET

Download PDF

Contact Info
Prepreg - Carbon Fiber (Grafil MR60H) Epoxy (Newport 301) - 39.7" x 0.0046" Thick - Unidirectional Intermediate Modulus (174 gsm OAW) - 250F Resin - 42 lb Roll *EXPIRED MATERIAL. BATCH # UNI12022101167 ROLL # 16 OR 20
P/N 14019-D-FULLROLL
