COMPOFLEX SB RF 3 - Non-Coated Peel Ply, Release Film & Flow Media in One - 60" wide
COMPOFLEX SB RF 3 ◾ Non-Coated Peel Ply, Release Ply & Flow Media ◾ 60" Wide
Compoflex® SB RF 3 is a peel ply, release film and flow mesh, used to control flow rate, distribute resin and release consumables from a composite laminate. Compoflex® SB RF 3 generates a very rough and textured surface ideal for secondary bonding or painting of a composite laminate. Compoflex® SB may reduce or eliminate the need for sanding or abrading. Best results with epoxy resin, but we always recommend testing. Release film perforation style: Low to medium bleed characteristics Compoflex® SB RF 3 is designed to efficiently distribute resin with limited waste due to the low profile and tight construction. Works well with polyester, vinylester, epoxy, phenolic and other types of resin.
You may also need
Additional Information
| P/N | 3045-D | 3045-D-FULLROLL |
|---|---|---|
| Abrasive Pad Finish | ||
| Application | ||
| Brand | Rock West Composites | Rock West Composites |
| Clearance | ||
| Color | ||
| Core Thickness | ||
| ECCN | ||
| Exportable | No | No |
| Finish | ||
| Height | ||
| Holesaw Size | ||
| HTS - Harmonized Tariff Code | ||
| Major ID | ||
| Major OD | ||
| Materials | Polyester Peel Ply | Polyester Peel Ply |
| Minor ID | ||
| Minor OD | ||
| Plate / Panel Size | ||
| REACH | ||
| RoHS | ||
| Router Bit Size | ||
| Saw Blade Arbor | ||
| Saw Blade Blade Type | ||
| Schedule B | ||
| USMCA Criterion | ||
| Weight | 0.9 | 76.0 |
| Width |
Technical Data
| Property |
Compoflex SB RF 3
|
Standard |
| Recommended working temperature |
145°C (293°F)
|
- |
| Fibre type |
Polypropylene (nonwoven)/High density Polyethylene (grid)
|
- |
| Fabric construction |
Nonwoven
|
- |
| Weight |
335 g/ m2 |
ISO 9864 |
| Thickness | 1.6 mm | ISO 9863 - 1 |
| Tear resistance MD/CD * | 280 N/188 N | ISO 9073 - 4 |
| Pore size | < 10 μm | ISO 12956 |
