P/N: 408-12-BLEM

P/N: 408-12-BLEM
$285.99
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.

Rock West Composites will NOT return or refund blowout or blemished items. This applies to all materials listed as a -blowout or a -blem.

This plate is fabricated via resin infusion and deploys a T700 (or equivalent) carbon fiber. In addition to being stiffer than aluminum carbon fiber plate this thicker version can be machined quite easily and shaped to yield a very interesting aesthetic often seen in knife handles or other products. Other manufacturers have dubbed this plate or ones similar "Artisan". Both sides have a peel ply finish which is matte / textured by default and with a quick cleaning can be bond ready.

Additional Information

P/N 408-12-BLEM
Application Tooling Plates / Support Structures
Finish Matte / Matte
HTS - Harmonized Tariff Code 6815.13.0000
Materials Standard Modulus Carbon
Plate / Panel Size 12" x 24" / 304.8mm x 609.6mm
Thickness 0.21
Weight 3.0
Width 12.0

Technical Data

13000-D FIBER or EQUIVALENT

This fiber is a T700G equivalent

Download PDF

RHINO RESIN

Download PDF

Tolerances

STOCK TOLERANCE SHEET

Download PDF

Contact Info
Plate - Twill - Matte/Matte - 12 x 24 x 0.21" / 5.3mm thick - BLEMISHED
P/N 408-12-BLEM
