Plate - Glass & Carbon Hybrid - Matte/Matte - 49 x 100 x 0.196" / 5mm thick - BLOWOUT

No Image found image number 0
No Image found image number 0
P/N: 47922

49" x 100" ◾ BLOWOUT

P/N: 47922
$2,875.99
Estimated lead time for quantities greater than what is Available Now is expected to be at least 4 weeks.

This plate has been produced using resin infusion and is comprised of Saertex 28oz. uni fiberglass & A&P BIMAX carbon fiber. The Ply orientation is following;

  • Fiberglass/Carbon/Carbon/Fiberglass/Carbon/Carbon/Fiberglass

Additional Information

Application Multi-Rotor / Drone / UAV
Materials Standard Modulus Carbon + Fiberglass
Pattern Stitched +/- 45
Color Black
Finish Matte / Matte
Panel Thickness 0.115
Plate / Panel Size 49" x 100"
Width 49.0
Thickness 0.21
Length 100
Weight 51.0
HTS - Harmonized Tariff Code 6815.13.0000
ECCN EAR99
REACH Not Applicable
RoHS Not Applicable

Tolerances

STOCK TOLERANCE SHEET

Download PDF
