Roll Wrapping Tape - Stage 1 - Non Stick - 300F Poly (White) - 1 Roll (~1.5 lbs)- 0.75" wide

productname image number 0
productname image number 1
productname image number 0
productname image number 1
P/N: 1536-D

P/N: 1536-D
1 - 4
$14.99
5 - 10
$12.79
11 - 49
$12.59
50 - 74
$10.39
75 +
$10.19
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.

White/Clear

Use our Shrink Tape Stage 1 directly against prepreg in your curing process. Stage 1 is naturally non-stick so it will release easily off of cured prepreg post cure. Stage 2 then is applied on top in order to provide even more shrinking force (where stage 2 can be wrapped tighter during the application process prior to cure)

FILM DESCRIPTION: B120-456 IS A BIAXALLY ORIENTED POLYPROPYLENE FILM DESIGNED TO BE USED IN THE MANUFACTURE OF CARBON FIBER COMPOSITE TUBING, IE: FISHING RODS, GOLF SHAFTS,

ARROWS, AEROSPACE, INDUSTRIAL TUBES, SAILING PARTS. THE FILM WAS DEVELOPED WHERE YOU NEED A THIN FILM TO WRAP COMPOSITE TUBES FOR CURING.

TECHNICAL PROPERTIES (120 GA) 30 MIC

THICKNESS: 1.2 MIL (30 MIC)

TENSION PROPERTIES: 5/8” WIDTH

ULTIMATE TENSILE: 26,400

TENSILE STRENGTH (@BREAK PSI): 24390

ELONGATION: 150

MELT POINT: 285 F (140 C)

TREATMENT: NO TREATMENT (32 DYNE LEVEL)

SHRINK: (1 HOUR @ 250 DEGREE F) 1.84%

You may also need

Additional Information

Thickness 0.047
Length 0
Weight 1.54
